JIC Swivel Fittings
Puab: Ncaj
Xov 1 Hom: Poj Niam JIC Swivel
Xov 2 Hom: Txiv neej yeeb nkab
JIC Swivel Fittings
Tshooj Naj Npawb:
6505
Yam ntxwv:
Puab: Ncaj
Xov 1 Hom: Poj Niam JIC Swivel
Xov 2 Hom: Txiv neej yeeb nkab
PART NO. SIZE | TUB OD | NPTF | SIB 37 | Ib DRILL | B DRILL | L LGTH | L5 LOJ | C1 HEX | C HEX |
6505-02-04 | 1/4 | 1/8-27 | 7/16-20 | 0.188 | 0.172 | 0.99 | 1.34 | 0.563 | 0.500 |
6505-02-05 | 5/16 | 1/8-27 | 1/2-20 | 0.188 | 0.234 | 1.03 | 1.41 | 0.625 | 0.562 |
6505-04-04 | 1/4 | 1/4-18 | 7/16-20 | 0.281 | 0.172 | 1.20 | 1.55 | 0.563 | 0.562 |
6505-04-05 | 5/16 | 1/4-18 | 1/2-20 | 0.281 | 0.234 | 1.26 | 1.64 | 0.625 | 0.562 |
6505-04-06 | 3/8 | 1/4-18 | 9/16-18 | 0.281 | 0.297 | 1.30 | 1.68 | 0.688 | 0.562 |
6505-06-04 | 3/8 | 3/8-18 | 7/16-20 | 0.406 | 0.172 | 1.23 | 1.58 | 0.563 | 0.750 |
6505-06-06 | 3/8 | 3/8-18 | 9/16-18 | 0.406 | 0.297 | 1.26 | 1.64 | 0.688 | 0.750 |
6505-06-08 | 1/2 | 3/8-18 | 3/4-16 | 0.406 | 0.391 | 1.31 | 1.74 | 0.875 | 0.875 |
6505-06-10 | 5/8 | 3/8-18 | 7/8-14 | 0.406 | 0.484 | 1.41 | 1.91 | 1.000 | 0.875 |
6505-08-06 | 3/8 | 1/2-14 | 9/16-18 | 0.531 | 0.609 | 1.51 | 1.89 | 0.688 | 0.875 |
6505-08-08 | 1/2 | 1/2-14 | 3/4-16 | 0.531 | 0.391 | 1.56 | 1.99 | 0.875 | 0.875 |
6505-08-10 | 5/8 | 1/2-14 | 7/8-14 | 0.531 | 0.484 | 1.60 | 2.10 | 1.000 | 1.000 |
6505-08-12 | 3/4 | 1/2-14 | 1-1/16-12 | 0.531 | 0.609 | 1.58 | 2.15 | 1.250 | 1.000 |
6505-12-08 | 1/2 | 3/4-14 | 3/4-16 | 0.719 | 0.391 | 1.67 | 2.10 | 0.875 | 1.125 |
6505-12-10 | 5/8 | 3/4-14 | 7/8-14 | 0.719 | 0.484 | 1.70 | 2.20 | 1.000 | 1.125 |
6505-12-14 | 7/8 | 3/4-14 | 1-3/16-12 | 0.719 | 0.719 | 1.74 | 2.32 | 1.375 | 1.250 |
6505-12-16 | 1 | 3/4-14 | 1-5/16-12 | 0.719 | 0.844 | 1.77 | 2.37 | 1.500 | 1.375 |
6505-16-16 | 1 | 1-11-1/2 | 1-5/16-12 | 0.938 | 0.844 | 1.97 | 2.57 | 1.500 | 1.375 |
6505-20-20 | 1-1/4 | 1-1/4-11-1/2 | 1-5/8-12 | 1.25 | 1.078 | 2.21 | 2.85 | 2.000 | 1.688 |
6505-24-24 | 1-1/2 | 1-1/2-11-1/2 | 1-7/8-12 | 1.5 | 1.312 | 2.27 | 2.99 | 2.250 | 2.000 |
6505-32-32 | 2 | 2-11-1/2 | 2-1/2-12 | 1.938 | 1.781 | 2.50 | 3.45 | 2.875 | 2.625 |
JIC Swivel Fittings
JIC Swivel fittings yog tsim los tso cai rau kev sib txuas thiab hose kev sib txuas kom tig, uas tiv thaiv kev sib tw, kinking thiab ntau dhau bending.... Lawv muaj ob yam tseem ceeb, qia thiab vaj tse uas tuaj yeem tig txheeb ze rau ib leeg, nrog rau sab hauv. seals thiab bearings
Cim npe nrov: jic swivel fittings, Tuam Tshoj, manufacturers, lag luam wholesale, hauv Tshuag, ua nyob rau hauv Suav teb
